XTCE185H22A
Eaton XTCE185H22A 185 AMP 3 pole contactor


Alternative Views:
EATON XTCE185H22A 185 AMP contactor with a 110/120 volt AC rated coil - Rated for 60 H.P @ 230 volt, 125 H.P. @ 460 volt 3 Phase - comes with two sets of side mounted auxiliary contacts, both with 1 N.O. and 1 N.C. contacts each

Not the correct contactor that you need? Click here to determine the appropriate Eaton XTCE for you.

XTCE185H22A Datasheet
List Price: $2,866.68
Our Price: $859.80
Savings: $2,006.88
Stock Items : Ships same day up until 4 p.m. EST
Non-Stock Items : 1-2 days for item to ship for standard delivery

Quantity in Stock:(Out of Stock)

Product Code: XTCE185H22A
Qty:

Description Detailed Specifications

The Eaton XTCE Size H IEC rated 3 pole contactors are the most durable, longest lasting contactors made today.  The XTCE line is identical to the Klockner Moeller DILM line and is just as reliable.  It is not uncommon for these contactors to last 10-15 years without needing to be replaced, thus saving both the time and expense of buying a new contactor.  And with ranges from 185A up to 500A, all of your low voltage contactor needs can be met.
Technical Specifications
  • AC control from 12V to 600V 50/60 Hz
  • DC control from 12V to 220V
  • Available with screw or spring cage terminals
  • Reversing or non-reversing contactors and starters
  • AC-3 contactor ratings to 1000A and AC-1 contactor ratings to 2000A
  • Non-reversing starters to 650A
  • Panel or DIN rail mounting to 65A
  • IP20 finger and back-ofhandproof
  • Large ambient temperature range, –25 to 50°C [–13 to 122°F]
