5SY41
Siemens 5SY41 Single Pole Breaker


Alternative Views:
Siemens 5SY41 Single pole Supplementary Circuit Breaker (must choose AMP and Trip Curve below) rated for 277 volt max and with tripping characteristic B, C or D type that mounts on standard 35mm DIN rail

Catalog Page / Specifications
List Price: $92.00
Our Price: $25.62
Savings: $66.38
Stock Items : Ships same day up until 4 p.m. EST
Non-Stock Items : 5-7 days for item to ship for standard delivery

Quantity in Stock:(Out of Stock)

Product Code: SIEMENS-5SY41


Siemens 5SY Trip Curves*:

Siemens 5SY AMP Rating*:

Qty:
Description Detailed Specifications

Siemens' UL 1077 5SY41 Supplementary Protectors are designed to provide additional protection along with a branch circuit protection device. Since these Supplementary protectors are made to trip faster than a standard UL 489 Circuit Breaker they are able to provide additional protection for more sensitive devices inside the panel. Supplementary protectors can be used in a number of industrial applications such as to provide selectivity for multiple motor control circuits on the secondary side of a control transformer or power supply by allowing the user to quickly find the problem circuit should a fault occur without having to shut down all of the other control circuits. Supplementary protectors may also be used as a local disconnecting means inside the panel when a branch circuit protection device is already present.
Technical Specifications
  • Siemesn 5SY41 MCB supplementary protectors are equipped with a delayed overload/ time-dependent thermal release (thermal bimetal) for low overcurrents and with an instantaneous electromagnetic release for high overload and short-circuit currents. The special contact materials used virtually guarantee a long service life and offer a high degree of protection against contact welding.
