Siemens 3RT1026-1A..4 25 AMP contactor

Alternative Views:

Siemens 3RT1026-1A..4 contactor that is rated for 25 AMPS and 15 H.P. @ 460v Three phase and an AC coil. Pre-installed top mounted 3RH1921-1HA22 adds 2 normally open and 2 normally closed contacts. Comes with screw terminals and can be mounted on DIN rail

Catalog Page / Specifications

Need help finding the coil voltage? Click here to see a picture to help determine the location of the coil voltage for this contactor.


Quantity in Stock:(Out of Stock)

Availability : Obsolete - No Availability from Siemens
Product Code: 3RT1026-1A..4
Qty:

Description Detailed Specifications


The Siemens Sirius line of 3RT1026-1A..4 contactors are suitable for use wherever a 3 pole, IEC, UL and CSA rated contactor is appropriate. This size S0 contactor is used in applications up to 15 horsepower at 460v for three phase applications. These contactors come with a 3RH1921-1HA22 4 pole auxiliary with 2 normally open and 2 normally closed contacts pre-mounted to the top. In addition to auxiliary contact blocks, thermal magnetic or solid state overload relays can be added to these Siemens contactors to provide full motor starter protection in the case of an over amperage situation. For mounting purposes, the contactors can either be mounted directly on standard 35mm DIN rail or screwed directly onto the back of the panel or mounting plate.
Technical Specifications

  • Siemens Size S0 contactor

  • Can be fitted with any 1-, 2- or 4-pole 3RH1921 auxiliary contactor for up to 4 additional contacts
  • For motor protection a 3RU1126 thermal overload or 3RB2026 Solid State overload relay can be directly mounted
  • Mounts on standard 35mm DIN rail or can be screw mounted
  • This contactor comes with screw termination - please call for spring/cage clamp terminals
  • The Sirius line can be fitted with optional varistors, surge suppressors or RC elements
